Blue Solder Mask Heavy Copper PCB Universal PCB Board Four Layers

Ask Lasest Price
Brand Name :	LEFANG
Model Number :	OT6002L366
Certification :	ISO9001, ISO14001, ISO/TS16949, SGS, UL, RoHs,OHSAS18000
Price :	Negotiable
Payment Terms :	T/T, Western Union, Paypal
Supply Ability :	290, 000sqm Per Month
Delivery Time :	2-10 work days

Add to Cart

Product Details
Company Profile

Blue Solder Mask Heavy Copper PCB Universal PCB Board Four Layers

Blue Solder Mask Immersion Gold 2 OZ Thick Copper PCB Board with RoHS

The blue sloder mask thick copper PCB is a 4 layers printed circuit board with 1.6 mm board thickness. While its copper thickness iS 2 OZ/ 70 µm, which is benefiial for heat dissipation.

How to get quick quotation?

Step 1 Please send us Gerber file with these format: .CAD / .Gerber / .PCB / .DXP / .P-CAD, etc

Step 2 Also please provide us the below details for quick quotation:

Board material: Fr - 4 / CEM - 1 / CEM - 3 / 22F / Fr - 1 / others

Material brand: SY / KB / Rogers (optional)

Material Specification:High Tg / copper based / aluminum based or others (optional)

Board thickness: 0.1 - 6.0 mm

Copper thickness: 0.05 Oz - 8 Oz ( 17 um - 288 um )

Surface Treatment: OSP / ENIG / HASL / Lead Free HASL / Immersion Tin / Immersion Sin

Color of solder mask and silk print: Green / red / blue / black / white / yellow ,etc

Board size and quantity

If you don't have Gerber file, please provide us the imfomation as step 2 or post your PCB Board to us for clone.

SAMPLE:

Board Basic Info - SAMPLE
Board material	Fr - 4
Material brand	KB
Material Specification	Tg 170
Board thickness	1.6 mm
Copper thickness	1 Oz
Surface Treatment	ENIG
Solder mask / sSilk print	Green / White
Board size	100 mm * 100 mm
Quantity	10k

Technical Data

Item	Details
Max layer count	20 L
Max board thickness	6.0 mm
Max aspect ratio	10 : 1
Max copper thickness	6 OZ
Max dimension	600 * 700mm
Min thickness of 4 layers PCB	0.4 mm
Min hole / pad	0.15 / 0.35mm
Hole location accuracy	+ / - 0.05mm
PTH hole tolerance	+ / - 0.05mm
Min line width and line space	0.065 / 0.065mm
Surface treatment	HASL / HASL lead free, OSP Immersion gold/silver/tin, gold plating (hard gold and soft gold), silver plating, tin plating, platinum plating, carbon ink, ENEPIG (electroless nickel - electroless palladium - immersion gold)

Lead Time

Layer count	Sample lead time/workday	Batch lead time/workday
1-2L	2	6
4L	5	8
6L	5	9
8L	6	10
10L	8	10
12L	8	12
14L	10	15
16L	10	18
18-40L (Up to difficulty)	at least 18	at least 24
P.S. For HDI, Blind/Buried Hole PCB: Regular Lead Time + 3 workdays

Why you can trust our products?

-- What LEFANG's vision is to Make Our Customer's Products Better, so we try our best to fulfill the quality control

system andenvironmental management system. Our approved certification are as below:

ISO9001:2008	ISO14001:2004
ISO/TS16949:2009	OHSAS18000
UL	RoHS
QC080000	CQC

Now send us your inquiry, and you will be replied within 8 hours!

Little knowledge - Single Sided PCB
Single sided PCB contains only one layer of conductive material, where components are focused on one side, and the other side of the wire is concentrated.
Single sided PCB are the best choice for low density designs. They are easily designed and quickly manufactured to serve as the most cost effective platform in the industry.
For surface finishes, single sided boards are available for Organic surface protectant (OSP), Immersion Silver, Tin, and Gold plating along with both leaded or lead-free Hot Air Solder Level (HASL), with operating temperatures range from 130℃ to 230℃.
