High TG170 Double-sided FR4 Automotive Printed Circuit Board with
1OZ Copper
Nowadays, many automotive on the market have advanced dashboards
that connect the vehicle to the radio or a passenger's phone or
music device. Undoubtedly, automotive PCB board is the necessary
part for the multimedia system of the vehicles. This automotive PCB
circuit board is 2 layers and double sided solder.
Why choose LEFANG?
Established in 1999, Lefang owns 3 modern Printed Circuit Board
factories in Guangdong, China.
We provide One-stop solution for PCB & PCBA manufacturing to our
customers home and abroad.
High quality PCB products, competitive price, on time delivery, after-sale service
are always offered.
To make the continued progress, we try our best to in every
section, including selecting quality raw materials
strictly, imported advanced automated equipments, employing 70
experienced engineers, acquiring global
certification of ISO9001:2008, ISO14001:2004, ISO/TS16949:2009, UL,
QC080000, OHSA18000, etc.
Our customers' industry come from Communication, Industrial
Control, Automotive, Medical Equipment,
Security Apparatus, Consumer Electronics and LED Lighting.
We sincerely pursue win-win business with customer all the time!
How to get quick quotation?
| Step 1 Please send us Gerber file with these format: .CAD / .Gerber / .PCB / .DXP / .P-CAD, etc |
| Step 2 Also please provide us the below details for quick quotation: |
Board material: Fr - 4 / CEM - 1 / CEM - 3 / 22F / Fr - 1 / others |
| Material brand: SY / KB / Rogers (optional) |
| Material Specification:High Tg / copper based / aluminum based or
others (optional) |
| Board thickness: 0.1 - 6.0 mm |
| Copper thickness: 0.05 Oz - 8 Oz ( 17 um - 288 um ) |
| Surface Treatment: OSP / ENIG / HASL / Lead Free HASL / Immersion
Tin / Immersion Sin |
| Color of solder mask and silk print: Green / red / blue / black /
white / yellow ,etc |
| Board size and quantity |
If you don't have Gerber file, please provide us the imfomation as
step 2 or post your PCB Board to us for clone.
|
SAMPLE:
|
Board Basic Info - SAMPLE | Board material | Fr - 4 | Material brand | KB | Material Specification | Tg 170 | Board thickness | 1.6 mm | Copper thickness | 1 Oz | Surface Treatment | ENIG | Solder mask / sSilk print | Green / White | Board size | 100 mm * 100 mm | Quantity | 10k |
|
Lead Time
| Layer count | Sample lead time/workday | Batch lead time/workday |
| 1-2L | 2 | 6 |
| 4L | 5 | 8 |
| 6L | 5 | 9 |
| 8L | 6 | 10 |
| 10L | 8 | 10 |
| 12L | 8 | 12 |
| 14L | 10 | 15 |
| 16L | 10 | 18 |
| 18-40L (Up to difficulty) | at least 18 | at least 24 |
| P.S. For HDI, Blind/Buried Hole PCB: Regular Lead Time + 3 workdays |
How to guarantee our high quality products?
-- We employ 70 professional engineers to ensure our high quality
products.
| Department | Headcount |
| Electronic Eng. | 13 |
| R&D Eng. | 15 |
| PE Eng. | 10 |
| CAM Eng. | 26 |
| MI Eng. | 6 |
Now send us your inquiry, and you will be replied within 8 hours!
Little knowledge - Thick copper PCB
Electronics are used in demanding environments and operate at
higher currents in these days.
Thick copper PCB can help conduct heat away from components and
withstand high current, satisfying the market of power conversion
module boards which is used in automobile electronics and electric
equipment.
Heavy copper PCBs means copper conductors 5 oz/ft2 – 19 oz/ft2 in
inner and/or outer layers; sometimes defined as more than 4 oz per
square foot (ft2).
These boards can be manufactured in a smaller footprint as they can
contain multiple weights of copper on the same circuit layers.
